Detailed Description

Ce module fournit les fonctions permettant de transmettre des informations sur des liaisons Ax25.

Collaboration diagram for Liaisons Ax25:

Modules
	Contrôleur de noeud terminal Ax25

	Interface C++

Classes
struct	xAx25

struct	xAx25Frame

struct	xAx25Node

Macros
#define	AX25_CALL_LEN 6

#define	AX25_CTRL_UI 0x03

#define	AX25_FRAME_BUF_LEN ((AX25_CALL_LEN+1)*(2+AX25_MAX_RPT)+AX25_INFO_LEN+4)

#define	AX25_INFO_LEN 256

#define	AX25_MAX_RPT 8

#define	AX25_PID_NOLAYER3 0xF0

HDLC flags.
These should be moved in a separated HDLC related file one day...
enum	eAx25Error { AX25_SUCCESS = 0, AX25_FILE_ACCESS_ERROR = -1, AX25_ILLEGAL_CALLSIGN = -2, AX25_INVALID_FRAME = -3, AX25_CRC_ERROR = -4, AX25_NOT_ENOUGH_MEMORY = -5, AX25_NOT_ENOUGH_REPEATER = -6, AX25_OBJECT_NOT_FOUND = -7, AX25_FILE_NOT_FOUND = -8, AX25_ILLEGAL_REPEATER = -9, AX25_NO_FRAME_RECEIVED = -10 }

typedef struct xAx25Node	xAx25Node

typedef struct xAx25Frame	xAx25Frame

typedef struct xAx25	xAx25

xAx25Node *	xAx25NodeNew (void)

void	vAx25NodeDelete (xAx25Node *n)

int	iAx25NodeClear (xAx25Node *n)

int	iAx25NodeSetCallsign (xAx25Node n, const char callsign)

char *	xAx25NodeToStr (const xAx25Node *p)

int	iAx25NodePrint (const xAx25Node *n)

int	iAx25NodeFilePrint (const xAx25Node n, FILE f)

xAx25Frame *	xAx25FrameNew (void)

void	vAx25FrameDelete (xAx25Frame *frame)

int	iAx25FrameClear (xAx25Frame *frame)

int	iAx25FrameSetSrc (xAx25Frame frame, const char callsign, uint8_t ssid)

int	iAx25FrameSetDst (xAx25Frame frame, const char callsign, uint8_t ssid)

int	iAx25FrameAddRepeater (xAx25Frame frame, const char callsign, uint8_t ssid)

int	iAx25FrameSetRepeaterFlag (xAx25Frame *frame, uint8_t index, bool flag)

int	iAx25FrameSetInfo (xAx25Frame frame, const void info, size_t info_len)

char *	xAx25FrameToStr (const xAx25Frame *frame)

int	iAx25FrameFilePrint (const xAx25Frame frame, FILE f)

int	iAx25FramePrint (const xAx25Frame *frame)

xAx25 *	xAx25New (void)

void	vAx25Delete (xAx25 *p)

int	iAx25Clear (xAx25 *p)

int	iAx25SetFdin (xAx25 *p, int fdin)

int	iAx25SetFdout (xAx25 *p, int fdout)

bool	bAx25Poll (xAx25 *ax25)

int	iAx25Send (xAx25 ax25, const xAx25Frame frame)

int	iAx25Read (xAx25 ax25, xAx25Frame frame)

int	iAx25Error (xAx25 *ax25)

#define	HDLC_FLAG 0x7E

#define	HDLC_RESET 0x7F

#define	AX25_ESC 0x1B

Macro Definition Documentation

#define AX25_CALL_LEN 6

#include <ax25.h>

Maximum number of characters in a AX25 callsign.

Definition at line 40 of file ax25.h.

#define AX25_CTRL_UI 0x03

#include <ax25.h>

Control field: UI This is the only value used in this lib so it is not possible to manage frames of another type.

Definition at line 57 of file ax25.h.

#define AX25_FRAME_BUF_LEN ((AX25_CALL_LEN+1)*(2+AX25_MAX_RPT)+AX25_INFO_LEN+4)

#include <ax25.h>

AX25 frame lenght without leading and trailling flags.

Definition at line 50 of file ax25.h.

#define AX25_INFO_LEN 256

#include <ax25.h>

Maximum number of bytes in a AX25 info field.

Definition at line 45 of file ax25.h.

#define AX25_MAX_RPT 8

#include <ax25.h>

Maximum number of Repeaters in a AX25 message.

Definition at line 35 of file ax25.h.

#define AX25_PID_NOLAYER3 0xF0

#include <ax25.h>

Protocol ID: No layer 3 protocol This is the only value used in this lib so it is not possible to manage frames of another type.

Definition at line 64 of file ax25.h.

Typedef Documentation

typedef struct xAx25 xAx25

#include <ax25.h>

AX25 Controller Class

typedef struct xAx25Frame xAx25Frame

#include <ax25.h>

AX25 Frame Class Used to handle AX25 sent/received messages.

typedef struct xAx25Node xAx25Node

#include <ax25.h>

AX25 Node Class

Enumeration Type Documentation

enum eAx25Error

#include <ax25.h>

List of error codes returned by the functions.

Definition at line 78 of file ax25.h.

              {

   AX25_SUCCESS                  =  0,
   AX25_FILE_ACCESS_ERROR        = -1,
   AX25_ILLEGAL_CALLSIGN         = -2,
   AX25_INVALID_FRAME            = -3,
   AX25_CRC_ERROR                = -4,
   AX25_NOT_ENOUGH_MEMORY        = -5,
   AX25_NOT_ENOUGH_REPEATER      = -6,
   AX25_OBJECT_NOT_FOUND         = -7,
   AX25_FILE_NOT_FOUND           = -8,
   AX25_ILLEGAL_REPEATER         = -9,
   AX25_NO_FRAME_RECEIVED        = -10

 } eAx25Error;

Function Documentation

bool bAx25Poll ( xAx25 * ax25 )

#include <ax25.h>

Check if there are any AX25 messages to be processed. This function read available characters from the medium and search for any AX25 messages. If a message is found, this function return true and the message can be read with iAx25Read(). This function may be blocking if there are no available chars and the FILE used in ax25 to access the medium is configured in blocking mode.

Parameters

ax25	AX25 object to operate on.

Returns: true if , negative value on error

int iAx25Clear ( xAx25 * p )

#include <ax25.h>

Clear all fields of the object

Returns: AX25_SUCCESS, negative value on error

int iAx25Error ( xAx25 * ax25 )

#include <ax25.h>

Retruns the last error code.

int iAx25FrameAddRepeater	(	xAx25Frame *	frame,
		const char *	callsign,
		uint8_t	ssid
	)

#include <ax25.h>

Adds a repeater to the frame

Parameters

frame	AX25 frame object to operate on.
callsign	Call string, max 6 character
SSID	(secondary station ID) for the call

Returns: Index of the new repeater (0 to AX25_MAX_RPT-1), negative value on error

int iAx25FrameClear ( xAx25Frame * frame )

#include <ax25.h>

Clear the frame

src and dst are cleared with iAx25NodeClear() All the repeaters are removed. The ctrl is set to AX25_CTRL_UI, the pid to AX25_PID_NOLAYER3.

Returns: AX25_SUCCESS, negative value on error

int iAx25FrameFilePrint	(	const xAx25Frame *	frame,
		FILE *	f
	)

#include <ax25.h>

Print a AX25 message in TNC-2 packet monitor format in a file

Parameters

f	a file channel where the message will be printed.
frame	the message to be printed.

int iAx25FramePrint ( const xAx25Frame * frame )

#include <ax25.h>

Print a AX25 message in TNC-2 packet monitor format.

Parameters

frame the message to be printed.

int iAx25FrameSetDst	(	xAx25Frame *	frame,
		const char *	callsign,
		uint8_t	ssid
	)

#include <ax25.h>

Sets the destination address of frame

Parameters

frame	AX25 frame object to operate on.
callsign	Call string, max 6 character
SSID	(secondary station ID) for the call

Returns: AX25_SUCCESS, negative value on error

int iAx25FrameSetInfo	(	xAx25Frame *	frame,
		const void *	info,
		size_t	info_len
	)

#include <ax25.h>

Sets the info field of frame

Parameters

frame	AX25 frame object to operate on.
callsign	Call string, max 6 character
SSID	(secondary station ID) for the call

Returns: AX25_SUCCESS, negative value on error

int iAx25FrameSetRepeaterFlag	(	xAx25Frame *	frame,
		uint8_t	index,
		bool	flag
	)

#include <ax25.h>

Sets the repeater flag

Parameters

frame	AX25 frame object to operate on.
index	index of repeater
flag	new flag value

Returns: AX25_SUCCESS, negative value on error

int iAx25FrameSetSrc	(	xAx25Frame *	frame,
		const char *	callsign,
		uint8_t	ssid
	)

#include <ax25.h>

Sets the source address of frame

Parameters

frame	AX25 frame object to operate on.
callsign	Call string, max 6 character
SSID	(secondary station ID) for the call

Returns: AX25_SUCCESS, negative value on error

int iAx25NodeClear ( xAx25Node * n )

#include <ax25.h>

Initialize all fields of the node

Parameters

n	node object to operate on.

Returns: AX25_SUCCESS, negative value on error

int iAx25NodeFilePrint	(	const xAx25Node *	n,
		FILE *	f
	)

#include <ax25.h>

Print the node in the file

Parameters

n	node object to operate on.

Returns: AX25_SUCCESS, negative value on error

int iAx25NodePrint ( const xAx25Node * n )

#include <ax25.h>

Print the node

Parameters

n	node object to operate on.

Returns: AX25_SUCCESS, negative value on error

int iAx25NodeSetCallsign	(	xAx25Node *	n,
		const char *	callsign
	)

#include <ax25.h>

Sets callsign of the node

Parameters

n	node object to operate on.
callsign	the new callsign (only the first 6 characters will be stored)

Returns: AX25_SUCCESS, negative value on error

int iAx25Read	(	xAx25 *	ax25,
		xAx25Frame *	frame
	)

#include <ax25.h>

Read the last AX25 frame received on the channel.

Parameters

ax25	AX25 object to operate on.
frame	copy of the last received message

Returns: AX25_SUCCESS, negative value on error

int iAx25Send	(	xAx25 *	ax25,
		const xAx25Frame *	frame
	)

#include <ax25.h>

Send an AX25 frame on the channel through a specific frame.

Parameters

ax25	AX25 object to operate on.
frame	massage to send

Returns: AX25_SUCCESS, negative value on error

int iAx25SetFdin	(	xAx25 *	p,
		int	fdin
	)

#include <ax25.h>

Sets the file descriptor used to gain access to the physical medium in input

Parameters

fdin	file descriptor

Returns: xAx25 initialized object, NULL if error.

int iAx25SetFdout	(	xAx25 *	p,
		int	fdout
	)

#include <ax25.h>

Sets the file descriptor used to gain access to the physical medium in output

Parameters

fdout file descriptor

Returns: xAx25 initialized object, NULL if error.

void vAx25Delete ( xAx25 * p )

#include <ax25.h>

Delete a xAx25 object

Parameters

p	object to operate on.

void vAx25FrameDelete ( xAx25Frame * frame )

#include <ax25.h>

Delete a xAx25Node object

Parameters

n	node object to operate on.

void vAx25NodeDelete ( xAx25Node * n )

#include <ax25.h>

Delete a xAx25Node object

Parameters

n	node object to operate on.

xAx25Frame* xAx25FrameNew ( void )

#include <ax25.h>

Create and initialize a new xAx25Frame object

This object should be deleted with vAx25FrameDelete()

Returns: pointer on the object, NULL on error

char* xAx25FrameToStr ( const xAx25Frame * frame )

#include <ax25.h>

Convert a frame to a string for display

Parameters

frame AX25 frame object to operate on.

Returns: The characters string should be deleted with free();

xAx25* xAx25New ( void )

#include <ax25.h>

Create and initialize a new xAx25 object

This object should be deleted with vAx25Delete()

Returns: pointer on the object, NULL on error

xAx25Node* xAx25NodeNew ( void )

#include <ax25.h>

Create and initialize a new xAx25Node object

This object should be deleted with vAx25NodeDelete()

Returns: pointer on the object, NULL on error

char* xAx25NodeToStr ( const xAx25Node * p )

#include <ax25.h>

Convert a node to a string for display

The format is AAAAAA-S* where AAAAAA is the callsign, S the ssid if no null and * is the has-been-repeated inficator.

Parameters

n	node object to operate on.

Returns: The characters string should be deleted with free();
